2026  Sport Haven  6x12 Aluminum Utility Trailer  - 46331

DRY WEIGHT: 700
GVWR: 2990
PAYLOAD CAPACITY: 2519

STANDARD FEATURES:
Construction Specs
Fluted Aluminum Tube Tongue, Tongue Supports, Frame & Crossmembers
2" Wide Top Deck Rail
2" x 2" Top Deck Rail Uprights
5/4" x 6" ProWood DuraColor Decking
All Aluminum 4' Rear Ramp

Component Specs
LED Lights
15" Silver Powder Coated Wheels
ST207/75R15C Radial Tires
3,500 lb Capacity Axles
Double Eye Spring Suspension
3,500 lb Capacity Zinc Plated Couplers
3,200 lb Capacity, 27" Safety Chains
1,200 lb capacity Swivel Wheel Jack

Misc Specs
4-Way Flat Wiring Harness
2" Ball
14" Hitch Height
17" Deck Height
13" Rail Height Above the Deck
2,990 lb Gross Vehicle Weight Rating (GVWR)

SPECS:
MODEL AUT612
Deck L x W 144” x 72”
Overall L x W 186” / 90”
Tongue* (1) 3" x 3" Fluted
Tongue Supports* (2) 1.75" x 3" Fluted
Frame Outer Rails* (2) 2" x 4" Fluted
Frame Crossmembers* Front & Rear (2) 3" x 4" Fluted
Frame Crossmembers* Middle** (5) 1.75" x 3" Fluted
Curb Weight 700 lbs
Payload Capacity 2,519 lbs
